Payload Type Development
This section describes new Payload Types

Creating a new Mythic agent

You want to create a new agent that fully integrates with Mythic. Since everything in Mythic revolves around Docker containers, you will need to ultimately create one for your payload type along with some specific files/folder structures. This can be done with docker containers on the same host as the Mythic server or with an external VM/host machine.
  • Optionally: You can also have a custom C2 profile that this agent supports, see C2 Profile Development for that piece though
The first step is to look into the First Steps page to get everything generally squared away and look at the order of things that need your attention. The goal is to get you up and going as fast as possible!

Payload/C2 Development Resources

There are a lot of things involved in making your own agent, c2 profile, or translation container. For the bare-bones implementations, you'll have to do very little, but Mythic tries to allow a lot of customizability. To help with this, Mythic uses PyPi packages for a lot of its configuration/connections and Docker images for distribution. This makes it easy for somebody to just kind of "hook up" and get going. If you don't want to do that though, all of this code is available to you within the MythicMeta organization on GitHub (https://github.com/MythicMeta).
This organization is broken out in five main repos:
  • Mythic_Scripting - This holds all of the code for the PyPi package, mythic, that you can use to script up actions.
  • Mythic_CLI - This holds all of the Golang code for the mythic-cli binary.
  • Mythic_Translator_Container - This holds all of the code for the PyPi package, mythic_translator_container, that you can use to build your own translation container.
  • Mythic_PayloadType_Container - This holds all of the code for the PyPi package, mythic_payloadtype_container, that you can use to create your own payload type docker image or when turning a vm into your own payloadtype container.
  • Mythic_C2Profile_Container - This holds all of the code for the PyPi package, mythic_c2_container, that you can use to create your own c2 profile docker image or when turning an arbitrary host into a c2 profile service.
  • Mythic_DockerTemplates - This holds all of the code and resources that are used to make all of the Docker images hosted on DockerHub (https://hub.docker.com/search?q=itsafeaturemythic&type=image). This is helpful if you want to see what's actually happening for a specific container or you want to use one of these as a starting point for your own containers.

Payload Type Docker Information

The rest of these sections talk about specifics for the docker container for your new agent.

Creating a docker container for your new agent

There are docker containers for each payload type which contain customized build environments. This allows two payload types that might share the same language to still have different environment variables, build paths, tools installed, etc. Docker containers come into play for a few things:
  • Metadata about the payload type (this is in the form of python classes)
  • The payload type code base (whatever language your agent is in)
  • The python code to create the payload based on all of the user supplied input
  • Metadata about all of the commands associated with that payload type (more python classes)
  • The code for all of those commands (whatever language your agent is in)
  • Browser scripts for commands and support scripts for the payload type as a whole (JavaScript)
  • The python code to take user supplied tasking and turn it into tasking for your agent
This part has to happen outside of the web UI at the moment. The web UI is running in its own docker container, and as such, can't create, start, or stop entire docker containers. So, make sure this part is done via CLI access to where Mythic is installed.
Within Mythic/Payload_Types/ make a new folder that matches the name of your agent. Inside of this folder make a file called Dockerfile. This is where you have a choice to make - either use the default Payload Type docker container as a starting point and make your additions from there, or use a different container base.

Using the default container base

The default container is pretty bare bones except for python 3.8. Start your Dockerfile off with:
From itsafeaturemythic/python38_payload:0.1.1
On the next lines, just add in any extra things you need for your agent to properly build, such as:
RUN pip install python_module_name
RUN shell_command
RUN apt-get install -y tool_name
This happens all in a script for docker, so if a command might make a prompt for something (like apt-get), make sure to auto handle that or your stuff won't get installed properly
There are a few different default containers you can leverage depending on the environment you need:
  • From itsafeaturemythic/python38_payload
    • This is based on python:3.8-buster and only has python3.8 installed
  • From itsafeaturemythic/csharp_payload
    • This is based on mono:latest with python 3.8.6 manually installed along with the System.Management.Automation.dll added in (v2 and v4)
  • From itsafeaturemythic/xgolang_payload
    • This is based on karalabe/xgo-latest with python 3.8.6 manually installed
The latest container versions and their associated mythic_payloadtype_container PyPi versions can be found here: Current PayloadType Versions.
If you're curious what else goes into these containers, look in the following repo:
Mythic_Docker_Templates/Docker_Payload_Type_base_files at master · MythicMeta/Mythic_Docker_Templates
GitHub

Required Folder Structure

The Mythic/Payload_Types/[agent name] folder is mapped to /Mythic in the docker container. Editing the files on disk results in the edits appearing in the docker container and visa versa.
All of your agent code, commands, and c2 profile code should be in the following folder: Mythic/Payload_Types/[agent name]/agent_code/. You can have any folder structure or files you want here.
The Mythic/Payload_Types/[agent name]/mythic folder contains all information for interacting with Mythic. Inside of the mythic folder there's a subfolder agent_functions where all of your agent-specific building/command information lives.
The entire folder structure can be copied from the Example_Payload_Type folder.
There isn't too much that's different if you're going to use your own container, it's just on you to make sure that python3.8 is up and running and the entrypoint is set properly. Here's what the base containers do:
Mythic_Docker_Templates/python38_dockerfile at master · MythicMeta/Mythic_Docker_Templates
GitHub
with the following requirements.txt file in them:
Mythic_Docker_Templates/requirements.txt at master · MythicMeta/Mythic_Docker_Templates
GitHub
Notice that it installs python3.8, sets it up correctly, installs the required packages (aio_pika, mythic-payloadtype-container, dynaconf) for Mythic, and sets the entrypoint for a default service file.
If you're having this hook up through Mythic via mythic-cli and the one docker-compose file, the dynaconf and mythic-payloadtype-container are the ones responsible for the Mythic/.env configuration being applied to your container.
If your container/service is running on a different host than the main Mythic instance, then you need to make sure the rabbitmq_password is shared over to your agent as well. By default, this is a randomized value stored in the Mythic/.env file and shared across containers, but you will need to manually share this over with your agent either via an environment variable (MYTHIC_RABBITMQ_PASSWORD or by editing the rabbitmq_password field in your rabbitmq_config.json file.

Starting your Docker container

To start your new payload type docker container, you need to first make sure that the docker-compose file is aware of it (assuming you didn't install it via mythic-cli install github <url> ). You can check if your docker-compose file is aware of your agent via mythic-cli payload list. If it's not aware, you can simply do mythic-cli payload add <payload name>. Now you can start just that one container via mythic-cli payload start <payload name>.
Your container should pull down all the necessary files, run the necessary scripts, and finally start. If it started successfully, you should see it listed in the payload types section when you run sudo ./mythic-cli status.
If you go back in the web UI at this point, you should see the red light next to your payload type change to green to indicate that it's now getting heartbeats. If it's not, then something went wrong along the way. You can use the sudo ./mythic-cli logs payload_type_name to see the output from the container to potentially troubleshoot.
The containers will automatically sync all of their information with the Mythic server when they start, so the first time the Mythic server gets a message from a container it doesn't know about, it'll ask to sync. Similarly, as you do development and restart your Payload Type container, updates will automatically get synced to the main UI.
If you want to go interactive within the container to see what's up, use the following command:
sudo docker exec -it {payload type name} /bin/bash
The container has to be running though.

Turning a VM into a Mythic container

There are scenarios in which you need a Mythic container for an agent, but you can't (or don't want) to use the normal docker containers that Mythic uses. This could be for reasons like:
  • You have a custom build environment that you don't want to recreate
  • You have specific kernel versions or operating systems you're wanting to develop with
So, to leverage your own custom VM or physical computer into a Mythic recognized container, there are just a few steps.
An easy way to do configuration for your agent outside of the rabbitmq_config.json file in step 6, is to use environment variables. These can be exported from your mythic-cli and .env file via: sudo ./mythic-cli config payload.
External agents need to connect to mythic_rabbitmq in order to send/receive messages. By default, this container is bound on localhost only. In order to have an external agent connect up, you will need to adjust this in the Mythic/.env file to have RABBITMQ_BIND_LOCALHOST_ONLY=false and restart Mythic (sudo ./mythic-cli restart). The sudo ./mythic-cli config payload will ask if you want to do this too.
  1. 1.
    Install python 3.8+ in the VM or on the computer
  2. 2.
    pip3 install mythic-payloadtype-container (this has all of the definitions and functions for the container to sync with Mythic and issue RPC commands). Make sure you get the right version of this PyPi package for the version of Mythic you're using (Current PayloadType Versions).
  3. 3.
    Create a folder on the computer or VM (let's call it path /pathA). Essentially, your /pathA path will be the new Payload_Types/[agent name] folder. From the Mythic install, copy the contents of Mythic/Example_Payload_Type to /pathA. So, you should have /pathA/agent_code/, /pathA/mythic/ and /pathA/Dockerfile (that last one won't matter for us though).
  4. 4.
    Your agent code will be in /pathA/agent_code/. You can create a Visual Studio project here and simply configure it however you need.
  5. 5.
    Your Mythic-based code (payload definitions, tasking functions, builder function, etc) will be in /pathA/mythic/.
  6. 6.
    Edit the /pathA/mythic/rabbitmq_config.json with the parameters you need
    1. 1.
      the host value should be the IP address of the main Mythic install
    2. 2.
      the name value should be the name of the payload type (this is tied into how the routing is done within rabbitmq). For Mythic's normal docker containers, this is set to hostname because the hostname of the docker container is set to the name of the payload type. For this case though, that might not be true. So, you can set this value to the name of your payload type instead (this must match your agent name exactly).
    3. 3.
      the container_files_path should be the absolute path to the folder in step 3 (/pathA/in this case).
    4. 4.
      leave virtual_host and username the same
    5. 5.
      You'll need the password of rabbitmq from your Mythic instance. You can either get this from the Mythic/.env file, by running sudo ./mythic-cli config get rabbitmq_password, or if you run sudo ./mythic-cli config payload you'll see it there too.
  7. 7.
    External agents need to connect to mythic_rabbitmq in order to send/receive messages. By default, this container is bound on localhost only. In order to have an external agent connect up, you will need to adjust this in the Mythic/.env file to have RABBITMQ_BIND_LOCALHOST_ONLY=false and restart Mythic (sudo ./mythic-cli restart). The sudo ./mythic-cli config payload will ask if you want to do this too.
  8. 8.
    In /pathA/mythic/agent_functions/builder.py is where you define the information about your new Payload Type as well as define what it means to "build" your agent. For starters though, just make sure that the name in the /pathA/mythic/rabbitmq_config.json file matches the name in the class definition here exactly.
  9. 9.
    Run python3.8 mythic_service.py and now you should see this container pop up in the UI
  10. 10.
    If you already had the corresponding payload type registered in the Mythic interface, you should now see the red light turn green.
You should see output similar to the following:
[email protected] mythic % python3 mythic_service.py
[*] To enable debug logging, set `MYTHIC_ENVIRONMENT` variable to `testing`
[*] Mythic PayloadType Version: 12
[*] PayloadType PyPi Version: 0.1.7
[*] Setting hostname (which should match payload type name exactly) to: test
[*] Trying to connect to rabbitmq at: 192.168.53.149:5672
[+] Ready to go!
[*] mythic_service - Waiting for messages in mythic_service with version 12.
[*] mythic_service - total instances of test container running: 1
If you mythic instance has a randomized password for rabbitmq_password, then you need to make sure that the password from Mythic/.env after you start Mythic for the first time is copied over to your vm. You can either add this to your rabbitmq_config.json file or set it as an environment variable (MYTHIC_RABBITMQ_PASSWORD).

Caveats

There are a few caveats to this process over using the normal process. You're now responsible for making sure that the right python version and dependencies are installed, and you're now responsible for making sure that the user context everything is running from has the proper permissions.
One big caveat people tend to forget about is paths. Normal containers run on *nix, but you might be doing this dev on Windows. So if you develop everything for windows paths hard-coded and then want to convert it to a normal Docker container later, that might come back to haunt you.

Debugging Locally

Whether you're using a Docker container or not, you can load up the code in your agent_code folder in any IDE you want. When an agent is installed via mythic-cli, the entire agent folder (agent_code and mythic) is mapped into the Docker container. This means that any edits you make to the code is automatically reflected inside of the container without having to restart it (pretty handy). The only caveat here is if you make modifications to the mythic/agent_functions files - these are Python files loaded up when the container starts, so they don't detect hot patches and will require you to restart your container to load up the changes sudo ./mythic-cli payload start [payload name]. If you're making changes to those from a non-Docker instance, simply stop your python3.8 mythic_service.py and start it again. This effectively forces those files to be loaded up again and re-synced over to Mythic.

Debugging Agent Code Locally

If you're doing anything more than a typo fix, you're going to want to test the fixes/updates you've made to your code before you bother uploading it to a GitHub project, re-installing it, creating new agents, etc. Luckily, this can be super easy.
Say you have a Visual Studio project set up in your agent_code directory and you want to just "run" the project, complete with breakpoints and configurations so you can test. The only problem is that your local build needs to be known by Mythic in some way so that the Mythic UI can look up information about your agent, your "installed" commands, your encryption keys, etc.
To do this, you first need to generate a payload in the Mythic UI (or via Mythic's Scripting). You'll select any C2 configuration information you need, any commands you want baked in, etc. When you click to build, all of that configuration will get sent to your payload type's "build" function in mythic/agent_functions/builder.py. Even if you don't have your container running or it fails to build, no worries, Mythic will first save everything off into the database before trying to actually build the agent. In the Mythic UI, now go to your payloads page and look for the payload you just tried to build. Click to view the information about the payload and you'll see a summary of all the components you selected during the build process, along with some additional pieces of information (payload UUID and generated encryption keys).
Take that payload UUID and the rest of the configuration and stamp it into your agent_code build. For some agents this is as easy as modifying the values in a Makefile, for some agents this can all be set in a config file of some sort, but however you want to specify this information is up to you. Once all of that is set, you're free to run your agent from within your IDE of choice and you should see a callback in Mythic. At this point, you can do whatever code mods you need, re-run your code, etc.

Callbacks Aplenty

Following from the previous section, if you just use the payload UUID and run your agent, you should end up with a new callback each time. That can be ideal in some scenarios, but sometimes you're doing quick fixes and want to just keep tasking the same callback over and over again. To do this, simply pull the callback UUID and encryption keys from the callback information on the active callbacks page and plug that into your agent. Again, based on your agent's configuration, that could be as easy as modifying a Makefile, updating a config file, or you might have to manually comment/uncomment some lines of code. Once you're reporting back with the callback UUID instead of the payload UUID and using the right encryption keys, you can keep re-running your build without creating new callbacks each time.
